| Nguồn gốc: | Trung Quốc |
|---|---|
| Hàng hiệu: | fanryn |
| Chứng nhận: | BS476Part 7∝Part6 |
| Số mô hình: | Tấm cách nhiệt cao su |
| Số lượng đặt hàng tối thiểu: | 1 * 20ft |
| Giá bán: | 0.1-5$ |
| chi tiết đóng gói: | túi nhựa |
| Thời gian giao hàng: | 7-10 ngày |
| Điều khoản thanh toán: | T/T |
| Khả năng cung cấp: | 10000 mét vuông |
| Kháng hóa chất: | Chống lại hầu hết các hóa chất | Loại cách nhiệt: | Nhiệt |
|---|---|---|---|
| Chống cháy: | Lớp 0, Lớp B1 | Tỉ trọng: | 40-90 kg/m3 |
| Hấp thụ âm thanh: | Cao | Phương pháp cài đặt: | Lỏng lẻo, batts hoặc cuộn |
| Ứng dụng: | Mái nhà, tường, sàn, ống, ống dẫn | Tác động môi trường: | Thân thiện với môi trường |
| Độ bền: | Lâu dài | Phạm vi nhiệt độ: | -50 ° C đến 110 ° C. |
| Chống ẩm: | Thuốc chống nước |
CLASS B0 Rubber Plastic Insulation Sheet
Designed for high-performance applications, the FANRYN Rubber Insulation Sheet sets a new standard in thermal insulation. It combines low thermal conductivity with superior energy efficiency and exceptional moisture resistance, guaranteeing long-term durability and measurable cost efficiency. The sheet features a standard charcoal-grey finish and incorporates advanced fire-retardant additives to ensure outstanding fire safety.
Meeting the requirements of rigorous European standards, FANRYN has gained strong international traction, with growing exports to key markets including Southeast Asia, the Middle East, Australia, and other regions worldwide.
Product Specifications
Dimensions & Tolerances
| Thickness | 10mm | 15mm | 20mm | 25mm | 30mm |
|---|---|---|---|---|---|
| Length per piece | 20m | 20m | 10m | 10m | 10m |
| Tolerance | +1.5 | +1.5 | +3.5 | +4 | +5 |
Technical Data
| Item | Unit | Specification | Standard |
|---|---|---|---|
| Density | Kg/m³ | 40~90 | GB/T 6343 |
| Temperature | ℃ | -50~110 | GB/T 17794 |
| Oxygen index | % | ≥40 | GB/T 2406 |
| SDR | ≤65 | GB 8627-1999 | |
| Water vapor permeability | Factor | ≥1.0*10⁴ | GB/T 17146-1997 |
| Water absorption ratio in vacuum | % | ≤10 | GB/T 17794-2008 |
| Dimension stability 105±3℃,7d | % | ≤10 | GB/T 8811 |
| Crack resistance | N/cm | ≥2.5 | GB/T 10808 |
| Compression resilience ratio | % | ≥70 | GB/T 6669 |
Applications
Maximize Building & HVAC Efficiency
Enhance air conditioning performance and cut energy costs with our specialized insulation, ideal for workshops and commercial buildings.
Optimize Industrial Processes
Achieve greater thermal stability with comprehensive insulation systems designed for temperature-critical containers and pipelines.
Control Industrial Acoustics
Reduce noise effectively with engineered sound absorption solutions for mechanical systems and demanding industrial environments.
Solve Specialized Challenges
Rely on high-performance insulation for protective gear, cleanrooms, and any application demanding precise temperature control.
Product Advantages
Maximize Energy Savings
Unlock substantial energy efficiency with ultra-low thermal conductivity that drastically reduces heat transfer.
Uncompromising Protection
Count on multi-layered reliability: superior fire resistance, built-in vibration damping, and a closed-cell structure that permanently blocks moisture.
Effortless Installation
Simplify complex projects with our flexible, easy-to-cut material that ensures a clean, professional finish every time.
